DIGITAL PROCESS THUMBWHEEL TIMER

We are renowned as the most popular enterprises in this industry, offering a wide range of DIGITAL PROCESS THUMB WHEEL TIMER.

digital-process-thumbwheel-timer

Specification:

  • Wheel timer has user friendly programming for ON/OFF time selection.
  • This Thumb wheel timer is well manufactured with topmost grade material in tandem with set market norms.
  • The offered MP Based timer is provided in numerous specifications as per the need of customers.
  • Pulse and Power on start Range 0…99.9/999 secs / mins selectable On Delay / Off Delay selectable.
  • Easy to set with thumbwheel switch Up/Down count selectable.
  • Out LED Available external Reset with Remote Optional Remote start and Reset Dual Control Relay.
  • Output Size available 72X72,96X96,96X192 mm.

MICROPROCESSOR BASED MULTIFUNCTION TIMER

We are renowned as the most popular enterprises in this industry, offering a wide range of MICROPROCESSOR BASED MULTIFUNCTION TIMER.

Specification:

  • Power on, Pulse start, Proximity/Photo sensor.
  • Range 0.1 sec to 9999 min.
  • Selectable ON Delay / Off Delay selectable.
  • Pulse/Gate trigger logic selectable Up/Down count selectable.
  • Out LED Available Front and external Reset 10 years run time memory backup.
  • Relay output with 230 VAC mains operated Size available 72X72, 96X96 mm.
  • Also have weekly/Daily Timer with RTC (00:00 to 23.59 HH:MM).
microprocessor-based-multifunction-timer

MICROPROCESSOR BASED PRESET / BATCH COUNTER / TIMER

We are renowned as the most popular enterprises in this industry, offering a wide range of MICROPROCESSOR BASED PRESET/BATCH COUNTER/TIMER.

batch-counter-timer

Specification:

  • Power on, Pulse start, Proximity/Photo sensor Preset.
  • Range : 0 to 9999 counts.
  • Batch Range : 0 to 999999 counts X factor for length meter 0.001 to 9.999 Up counting with Output LED Available Front and external Reset 10 years run time memory backup.
  • Relay output with : 230 VAC mains.
  • Operated Size available : 72X72, 96X96 mm.
  • Batch Timer Range : 9999sec/min.
  • Total : 999999 se/min.

MULTIFUNCTION TIMER / COUNTER / TACHOMETER

We are renowned as the most popular enterprises in this industry, offering a wide range of MULTIFUNCTION TIMER/ COUNTER/TACHOMETER.

Specification:

  • Power input : 100~240VAC, 50/60Hz or DC24V.
  • Range of input voltage : 85%~110%, rated voltage or DC21.6V~26.4V.
  • Power consumption : less than 10VA or 5W.
  • External power supply : 12VDC ± 10%; 100mA.
  • Display : Double-line 6-digit LCD display.
  • NPN input : ON impedance 1K ohm max.
  • ON residual voltage : 2V max.
  • PNP input: high level : 4.5~30VDC; low level: 0~2VDC.
  • low level : 0~2VDC.
  • Dielectric strength : 2,000VAC; 50/60Hz for 1 minute international dimension and CE, UL international safety approvals.
multifunction-timer-counter-tacho-meter

SOLID STATE RELAY / PHASE ANGLE REGULATOR

We are renowned as the most popular enterprises in this industry, offering a wide range of SOLID STATE RELAY/PHASE ANGLE REGULATOR.

solid-state-relay

Specification:

  • The elman Solid State Relay accept DC voltage (4-32 VDC).
  • Variable current : (4-20 mA).
  • AC Voltage : (12-230VAC).
  • Variable ohms : (0-470 K).
  • The SSR/PPC soft start no noise Long life work.
  • Use proper heat sink avoid rejection.
  • The SSR work ON /OFF mode function only controlled by controller suitable for heater application.
