Gold Annealing Furnace by elman
The Superb melt annealing furnace is designed for heating metal work pieces above recrystallization temperature and then cooling the material once it has been held at the desired temperature for a period of time.
The annealing furnace goes through 3 stages, which are; the recovery stage, recrystallization stage and the grain growth stage. This whole process is done under the ammonia gas protection to prevent the work piece surface from oxidation, colour change, etc.
The annealing furnace is widely used for chain welding annealing, metal tempering, jewelry annealing, etc. Superb melt annealing furnace improves the machinability, mechanical and electrical properties of work piece metals.
The maximum power required for the metal annealing furnace is only 9kw, while the ammonia decomposition power is only 5kw. Superb melt annealing furnace is equipped with a PID intelligent temperature control, 24 hours alarm and water timer switch, for a safe and efficient metal annealing process.
Specification
| Title | Description |
|---|---|
| Temperature | Up to 1200° C |
| Chamber design | Cylinder/Rectangular |
| Insulation | Ceramic Fiber blankets / Modules, Conventional Refractory Brick Lining |
| Heating Media Options | Ele /Gas / Diesel / Oil fired |
| Furnace classification | Class 2, Class 3 |
| Heating Element | Ni/Cr – Kanthal etc., |
| Instrument option | Programmable temperature controller |
Related products
Interested to Know further?
Click on get quotes button below
- Superb melt annealing furnaces reduce the brittleness of metals while enhancing their magnetic properties and electrical conductivity.
- The collecting basket and water tank are used to collect work pieces and for immediate cooling of work pieces respectively.Â
- Tempering
- Normalizing
- Post Weld Heat
- Treatment
- Wire Annealing
- Isothermal Annealing
- Case Hardening
- Blueing
- Austempering
- Austenitizing
- Homogenizing
- The annealing furnace heats work pieces above the recrystallization temperature, the work piece becomes more ductile, therefore, ready to be worked once more.
- The annealing furnace removes stresses that can occur when a metal work piece solidifies.
- The annealing furnace for sale has an ammonia decomposition switch, alarm and timer switch to allow proper control and monitoring of the annealing process.
- Metal work pieces are heated within 40 to 60 minutes, this contributes to a fast and efficient annealing process during production.
- Large inside volume for even heat distribution.
